No.

Parts

specification

parameter

1

structure

Shell

1.5 mm galvanized steel plate, spray outdoor special power on the surface, protection for 7 years.

The door takes waterproof structure design, outdoor rubber seal, meet the IP65 protection grade.

glass

Using industrial grade 6 mm AR explosion-proof glass

2

monitor

LCD display area

32/43 inch

Aspect Ratio

16：9

Resolution

1920*1080

Brightness

1500 nits

View angle

178° level / 178°vertical

Adjust brightness

automatic

Backlight

LED backlight

touch

Touch

Capacitive/no touch

3

Motherboard

Motherboard

Android or Windows

WIFI

Yes

Display software

Support networking program distribution,

Local program update,

 Personal version mode play

4

Electronic control

Power switch

Industrial power

Waterproof speaker

Industrial waterproof high quality 10w speaker

lightening protector

Three level lightning protection（Military quality）

Leakage protector

yes

Timer

Can be set up by the day, week, month automatically switch machine

5

Heat dissipating

Intelligent ventilation system

Air cooling or air conditioner

High temperature automatically shutdown machine

6

Other

weight

100KG

7

operational parameter

operating temperature

-40℃~+55℃

operating humidity

5%~95%

operating humidity

AC 220V/50Hz

Max power consumption

200W
